Designed to obtain better performance in high-power tractors, RUUBI has in its DNA characteristics such as laminar erosion, elimination of the harrow foot (breakdown of the subsurface compacted layer) and removal of pivoting roots (cotton stump)
Check out the main highlights and unique features of the product.
Wheel hub
Wheel hub
Wheel hub with permanent lubrication, robustness with longer operational life ensuring safety over long distances.
Wheel hub with permanent lubrication, robustness with longer operational life...
Wheel hub
Wheel hub with permanent lubrication, robustness with longer operational life ensuring safety over long distances.
Structure
Structure
High-resistance structure: Up to 521 kg/disc (version 26 discs with ballast).
High-resistance structure: Up to 521 kg/disc (version 26 discs with ballast).
Structure
High-resistance structure: Up to 521 kg/disc (version 26 discs with ballast).
Removable ballast
Removable ballast
Removable 780 kg ballast, versatility and high efficiency in all terrain conditions.
Removable 780 kg ballast, versatility and high efficiency in all terrain cond...
Removable ballast
Removable 780 kg ballast, versatility and high efficiency in all terrain conditions.
Wheelset
Wheelset
Standard: 400/55-22.5 (Ruubi 24 discs) / Standard: 500/60-22.5 (Ruubi 26, 28 and 30 discs
Standard: 400/55-22.5 (Ruubi 24 discs) / Standard: 500/60-22.5 (Ruubi 26, 28 ...
Wheelset
Standard: 400/55-22.5 (Ruubi 24 discs) / Standard: 500/60-22.5 (Ruubi 26, 28 and 30 discs
Self-tightening system
Self-tightening system
Self-tightening system: Up to 1000ha without retightening in the front disc section.
Self-tightening system: Up to 1000ha without retightening in the front disc s...
Self-tightening system
Self-tightening system: Up to 1000ha without retightening in the front disc section.
| High-resistance structure | Up to 521 kg/disc (version 26 discs with ballast) |
| Removable 780 kg ballast | Versatility and high efficiency in all terrain conditions |
| Self-tightening system | Up to 1000ha without retightening in the front disc section |
| Wheelset |
Standard: 400/55-22.5 (Ruubi 24 discs) Standard: 500/60-22.5 (Ruubi 26, 28 and 30 discs) |
| Wheel hub with permanent lubrication | Robustness with longer operational life ensuring safety over long distances |
| Bearing Booster bearing of high resistance and durability | Components in special treatment, preserving the life of the interface assembly |
| Model | NR of Discs | Working Width | Shaft Diameter | Disc Diameter | Shaft Diameter | Tractor Power | |||
|---|---|---|---|---|---|---|---|---|---|
|
RUUBI |
24 | 5950 | 2.1/2" | 36" | 38" | 40" | 42" | 200-400 | 600 - 620 |
| 26 | 6460 | 2.1/2" | 36" | 38" | 40" | 42" | 200-400 | 630 - 650 | |
| 28 | 6920 | 2.1/2" | 36" | 38" | 40" | 42" | 200-400 | 650 - 680 | |
| 30 | 7380 | 2.1/2" | 36" | 38" | 40" | 42" | 200-400 | 690 - 720 | |
| Model | NR of Discs | Disc Spacing | Number of Tires | Tire model | Approximate weight w/ 42º discs without ballast | Approximate weight w/ 42º discs with ballast | |||
|---|---|---|---|---|---|---|---|---|---|
|
RUUBI |
24 | 508 | 4 | 400/55-22.5 | 11720 | 12500 | |||
| 26 | 508 | 4 | 500/60-22.5 | 12770 | 13550 | ||||
| 28 | 508 | 4 | 500/60-22.5 | 13420 | 14200 | ||||
| 30 | 508 | 4 | 500/60-22.5 | 13960 | 14740 | ||||
Standard: 42” Discs. / Optional: 36”, 38” and 40” Discs.
